Science Art

Engineering is an ever fascinating field, here I share some of the less seen artistic forms that it takes. All the content is derived from my research work.

Lattice Structures Mosaic

CAD isometric view of octet lattice structure (wire-frame) in CATIA

Electron beam melting 3D printed Ti-6Al-4V lattice structure

X Ray Diffraction Patterns

X-ray diffraction frame view (merged) of Titanium Nitride film on Titanium

Thin Film Rainbow

Titanium Nitride film through an optical microscope (defect)

Nano-indentation Pyramids

Indentations on a thin film using a Berkovich diamond tip

Thread Pitch Mountains

At Night: Thread section of a M6 × 1.0 bolt through optical microscope (5X dark field)

Daytime: Thread section of a M6 × 1.0 bolt through optical microscope (5X bright field)
